16ch Analog x 8ch IP, 8MP Resolution, Hybrid NVR

16ch Analog x 8ch IP, 8MP Resolution, Hybrid NVR

HNR162X-2T

$519.00 USD
$519.00 USD
Sale Sold out
warranty badge
Free returns
One Click Free Returns

(30 Days Complete Risk Free Returns)

90 Days Easy Return
Free Shipping

(Enjoy Free Shipping on this Product)

Key Features
  • Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
  • 16 analog x 8 IP Cameras, Hybrid network recorder with H.265 Compression
  • Simultaneously supports 16 Analog (AHD, TVI, CVI and CVBS) and 8 IP Video Inputs with adaptive access (or up to 24 IP channels if no analog cameras are connected)
  • Supports High Definition Analog (HD Analog) over Coax Technology for use of Existing Coax Cables & BNC Connectors, allowing mega-pixel video images from AHD, TVI and CVI camera without any rewiring
  • Supports recording of up to 8MP Resolution for HD Analog and IP Cameras
  • Concurrent Mirrored Display on HDMI and VGA Monitor Outputs
  • HDMI display resolution up to 8MP
  • Supports Audio I/O and PTZ Camera control
  • Easy Plug and Play Functionality with Automatic Device Discovery and Display
  • Supports 2 SATA HDD up to 10TB each
  • ONVIF Profile S Compliant for IP Cameras
  • Long transmission distance over RG-6 coax cable up to 2000ft (600m)
  • Supported by uniview tec Guard Station Client Software and Guard Viewer Mobile App’s for iPhone and Android Devices
Video & Audio Inputs
Analog Video Input 16-ch, BNC
IP Video Input 8-ch (only IP up to 24ch); each channel up to 8MP
Supported Analog Camera Types Support AHD input:
8MP @ 15fps
5MP @ 20fps
4MP @ 30fps
1080P @ 30fps
720P @ 30fps
Support TVI input:
8MP @ 15fps
5MP @ 20fps
4MP @ 30fps
1080P @ 30fps
720P @ 30fps
Support CVI input:
8MP @ 15fps
5MP @ 25fps
4MP @ 30fps
1080P @ 30fps
720P @ 30fps
Support CVBS input
Audio Input 1-ch, RCA
Audio Compression G.711U
Video & Audio Outputs
CVBS Output 1-ch, BNC
VGA Output 1920 x 1080p / 60Hz, 1920 x 1080p / 50Hz, 1600 x 1200 / 60Hz, 1280 x 1024 / 60Hz, 1280 x 720 / 60Hz, 1024 x 768 / 60Hz
HDMI Output 3840 x 2160 / 30Hz, 1920 x 1080p / 60Hz, 1920 x 1080p / 50Hz, 1600 x 1200 / 60Hz, 1280 x 1024 / 60Hz, 1280 x 720 / 60Hz, 1024 x 768 / 60Hz
Audio Output 1-ch, RCA
Synchronous Playback 16
Live view display HDMI / VGA: 1 / 4 / 6 / 8 / 9 / 16 / 25
Two-way Audio 1-ch, RCA
Snapshot
FTP/Schedule/Event Snapshot 16-ch snapshot, up to 704 x 576 resolution
Network
Incoming Bandwidth 80Mbps (Up to 112Mbps after all analog channel conversion)
Outgoing Bandwidth 160Mbps
Remote Users 128
Protocols TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP
Supported Browsers IE(IE10/11) for Windows
Firefox (version 52.0 and above) for Windows
Chrome(version 45 and above) for Windows
Edge(version 79 and above) for Windows
Encoding
Recording Resolution 8MP Lite / 5MP Lite /4MP Lite / 1080P / 720P / CIF
Recording
Frame Rate
Main stream Sub stream
8MP Lite @ 8fps D1 @ 8fps
5MP Lite @ 12fps D1 @ 12fps
4MP Lite @ 15fps D1 @ 15fps
1080P @ 15fps D1 @ 15fps
720p @ 30fps D1 @ 30fps
Audio Sample Rate 8KHz,16 bit per channel
Audio Bit Rate 64Kbps per channel
Decoding
Capability (fps) Analog: 16 x 8MP Lite @ 8, 16 x 5MP Lite @ 12, 16 x 4MP Lite @ 15, 16 x 1080P @ 15, 16 x 720P @ 30
IP: 24 x D1 @ 30, 16 x 720P @ 30, 8 x 1080P @ 30
Hard Disk Drives
SATA 2 SATA Interface
Capacity Up to 10TB for each HDD
Smart Alarm
VCA Detection Ultra Motion Detection (UMD) for analog: 8-ch
VCA Search Behavior Search
General Alarm
General Alarm Motion detection
Alert Alarm IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk
Full, Recording/Snapshot Abnormal
External Interface
Network Interface 1 RJ45 10M/100M/1000M self-adaptive Ethernet Interface
USB Interface Rear panel: 1 x USB3.0, Front panel: 1 x USB2.0
Serial Interface 1 x RS485
Alarm In 4
Alarm Out 1
General
Power Supply 12V DC; Power Consumption: ≤ 12 W( without HDD )
Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions (W × D × H) 380 × 326 × 53mm (15 × 12.8 × 2.1")
Weight (without HDD) 2Kg (4.4lb)
General
Certifications FCC, CE (UL – Power Supply only)
