Key Features
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- High Video Quality with 2MP, 1920 x 1080 Resolution
- High Definition Analog (HD Analog) over Coax Technology, utilizes existing Coax Cables & BNC Connectors, allowing Mega-pixel Video Images without any rewiring necessary
- TVI, AHD, CVI and CVBS Protocol selectable --- Engineered to work with UVT Hybrid NVR’s for Maximum Stability and Performance
- ColorHunter Technology allows 24/7 Full-Color Imaging with White Light Illumination
- 2.8mm fixed lens
- TRUE Day/Night and DWDR functionality for all Lighting Conditions
- Backlight Compensation and 2D DNR (Digital Noise Reduction)
- Supports 180° horizontal flip, 180° vertical flip
- Easy to Operation On Screen Display (OSD) Configuration Menu
- 12VDC Power Options; IP67 Weather Resistant Housing with Optional Mounts
- Supported by uniview tec Guard Station Client Software and Guard Viewer Mobile App’s for iPhone and Android Devices
Sensor | |
---|---|
Pixel | 2MP |
Size | 1/2.9" CMOS |
Minimum illumination | 0.005 lux (F1.4, AGC ON) 0 lux (white light on) |
Lens | |
Focal Length | 2.8mm |
Angle of View (H x V) | 101.5° x 56.9° |
IR Illumination | |
White Light | Two Illuminator; 40M (130ft) |
Video | |
Resolution | 1080P: 1920(H)×1080(V) 720P: 1280(H) ×720(V) |
Frame rate | TVI/AHD/CVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps CVBS: PAL, NTSC |
Shutter time | PAL: 1/25s-1/50000s NTSC: 1/30s–1/50000s |
Image | |
Exposure mode | 4 modes: Global (default), BLC, HLC, DWDR |
Day/Night | 24/7 full-color imaging |
Digital noise reduction | 2D / 3D |
White balance | Two modes: Auto (default), Manual |
WDR | DWDR |
Flip | Supports 180° horizontal flip, 180° vertical flip. |
Defog | Digital |
Audio | |
Microphone | Built-in |
Camera Audio | TVI: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps |
Interface | |
Power | 5.5mm power interface |
Video output | BNC, supports TVI / AHD / CVI / CVBS |
Operating Environment | |
Temperature | -30℃ to 60℃ (-22℉ to 140℉) |
Humidity | ≤95% (RH, non-condensing) |
Surge protection | 4KV |
Ingress protection | IP67 |
General | |
Power | DC 12V(±25%), with reverse polarity protection and surge protection, Max 3.12W |
Mount | 3D bracket supplied, surface mount (default); optional junction box and pole mount available |
Dimensions (L x W x H) | 157.4 x 67 x 66mm (5.6 x 2.4 x 2.6”) |
Material | Metal and Plastic |
Weight | 279g (0.62lb) |
Certification | CE, FCC |
