| Sensor |
1/2.7” 5MP, progressive scan CMOS |
| Minimum illumination |
Color: 0.005 lux (F1.6, AGC ON); 0 lux with IR on |
| True Day / Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto / Manual, 1 ~ 1/100000s |
| Adjustment angle (3-way Axis) |
Pan: 8° ~ 360°; Tilt: 0° ~ 68°; Rotate: 10° ~ 360° |
| WDR |
120dB |
| S/N |
>56dB |
| Lens |
| Lens |
2.8mm @ F1.0 |
| Iris |
Fixed |
| Field of View (H) |
112.9° |
| Field of View (V) |
59.1° |
| Field of View (D) |
121.2° |
| DORI |
| DORI Distance |
|
Detect (m)
84
|
Observe (m)
33.6
|
Recognize (m)
16.8
|
Identify (m)
8.4
|
|
| Illuminator |
| IR Range |
Up to 30m (98ft) IR range |
| Wavelength |
850nm |
| IR On/Off Control |
Auto/Manual |
| Video |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main profile, High profile |
| Frame Rate |
Main Stream: 8MP (3840 x 2160), Max 20fps; 5MP (3072 x 1728), Max 30fps; 4MP (2560 x 1440), Max 30fps; 1080P (1920 x
1080)
Sub Stream: 1080P (1920 x 1080), Max 30fps; 720P (1280 x 720) Max 30fps; D1 (720 x 576), Max 30fps; 640 x 360, Max
30fps; 2CIF (704 x 288), Max 30fps; CIF (352 x 288), Max 30fps
|
| Video Bit Rate |
128 Kbps~16 Mbps |
| U-code |
Supported |
| OSD |
Up to 4 OSDs |
| Privacy Mask |
Up to 4 areas |
| ROI |
Up to 8 areas |
| Video Stream |
Dual |
| Image |
| White Balance |
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2 |
| Digital Noise Reduction |
2D / 3D DNR |
| Smart IR |
Supported |
| Flip |
Normal / Vertical / Horizontal / 180° / 90°Clockwise / 90°Anti-clockwise |
| HLC |
Support |
| BLC |
Support |
| Defog |
Digital Defog |
| Intrusion Events |
| Basic Detection |
Motion detection, Ultra motion detection, tampering alarm, audio detection |
| General Function |
Watermark, IP address filtering, tampering alarm, alarm input, alarm output, access policy, ARP protection, RTSP
authentication, user authentication |
| Audio |
| Audio Compression |
G.711U, G.711A |
| Audio Bitrate |
64 Kbps |
| Suppressione |
Support |
| Sampling Rate |
8KHZ |
| Storage |
| Edge Storage |
Micro SD, up to 256GB |
| Network Storage |
ANR |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS,
SSL/TLS, SNMP, SSH |
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
| User/Host |
Up to 32 users. 3 user levels: administrator and common user |
| Security |
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP,
Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Client |
Guard Station, Guard Viewer |
| Web Browser |
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above;
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
| Interface |
| Built-in Mic |
Support |
| Network |
1 * RJ45 10M/100M Base-TX Ethernet |
| General |
| Power |
DC 12V±25%, PoE (IEEE 802.3af); Power consumption: Max 4.5W |
| Power Interface |
Ø 5.5mm coaxial power plug |
| Dimensions (Ø × H) |
Ø 109 x 83mm ( Ø 4.3 x 3.3”) |
| Weight |
0.43kg (0.99lb) |
| Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection |
4KV |
| Conformity Certifications |
IP67, CE, FCC |
