Key Features
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- LightHunter illumination technology ensures ultra-high color image up to 0.003 Lux (F1.6)
- Exceptional Video Quality with 4MP, 2688 x 1520 Resolution
- Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
- Powerful, Smart IR LED Lights for 0 Lux Night Time Operation up to 98 Feet
- 2.8 fixed lens, Triple Video Streams and ONVIF Profile S Compliant, PoE & 12VDC Power Options
- TRUE Day/Night and WDR functionality for all Lighting Conditions
- Built in microphone, Corridor View, Backlight Compensation and 3D DNR (Digital Noise Reduction)
- Intelligent, smart intrusion prevention technology for significantly reduced false alarms when focusing on humans and motor vehicles
- IP67 Weather Resistant Housing, with Optional Wall and Pendant Mounts Available
- Built-in Micro-SD Card Slot enables local storage up to 256GB
- Supported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Devices
Camera | |
---|---|
Sensor | 1/3", progressive scan , 4 megapixel, CMOS |
Lens | 2.8mm @ F1.6 |
Angle of View (H x V) | 101.1° x 55.3° |
Shutter | Auto/Manual, 1/6 ~ 1/100000 s |
Minimum Illumination | Color: 0.003 Lux (F1.6, AGC ON); 0 Lux with IR |
Day/Night | IR-cut filter with auto switch (ICR) |
Digital noise reduction | 2D/3D DNR |
IR LED Range & Wavelength | Up to 30m (98 ft) IR range; 850nm |
WDR & Defog | 120dB; Digital Defog |
Video Compression & Bit Rate | Ultra 265, H.265, H.264, MJPEG; 128 Kbps ~ 16 Mbps |
H.264 code profile | Baseline profile, Main Profile |
Maximum Frame Rate / Stream | Main: 4MP (2688 x 1520)@ 30fps Sub: 720p (1280 x 720) @ 30fps Third Stream: D1 (704 × 576) @ 30fps |
HLC, BLC, 9:16 Corridor, Flip | Supported |
OSD, Privacy Mask, Motion Detection & ROI |
Up to 8 areas |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
Network | RJ45, 10M/100M Base-T X Ethernet |
Smart Intrusion Prevention | Cross Line, Intrusion, Enter Area, Leave Area detection; Motion detection |
Local & Network Storage | Micro SD, up to 256 GB; ANR |
General | |
Power | 12 VDC +/- 25%, PoE (IEEE802.3 af); Power consumption: Max 4W |
Audio & Compression | Built-in Microphone; G711 |
Dimensions (Ø x H) & Weight | Φ110.5 x 94.1mm (Ø4.4 x 3.7”); 0.42kg (0.93lb) |
Operating Temperature & Humidity |
-30°C ~ +60°C (-22°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing) |
Conformity Certifications | IP67, CE, FCC |
