Key Features
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- LightHunter illumination technology ensures ultra-high color image up to 0.003 Lux (F1.6)
- Exceptional Video Quality with 4MP, 2688 x 1520 Resolution
- Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
- Powerful, Smart IR LED Lights for 0Lux Night Time Operation up to 98 Feet
- 4mm fixed lens; Triple Video Streams & ONVIF Profile S Compliant
- TRUE Day/Night and WDR functionality for all Lighting Conditions
- Built-in microphone, Backlight Compensation and 3D DNR (Digital Noise Reduction)
- Corridor View, Triple Video Streams & ONVIF Profile S Compliant
- Intelligent, smart intrusion prevention technology for significantly reduced false alarms when focusing on humans and motor vehicles
- Built-in Micro-SD Card Slot enables local storage up to 256GB; PoE & 12VDC Power Options
- IP67 Weather Resistant Housing; Optional Wall and Pole Mount Available
- Supported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Devices
Camera | |
---|---|
Sensor | 1/3", progressive scan , 4 megapixel, CMOS |
Lens | 2.8mm @ F1.6 |
Angle of View (H x V) | 101.1° x 55.3° |
Shutter | Auto/Manual, 1 ~ 1/100000 s |
Minimum Illumination | Color: 0.003 Lux (F1.6, AGC ON); 0 Lux with IR |
Day/Night | IR-cut filter with auto switch (ICR) |
Digital noise reduction | 2D/3D DNR |
Signal / Noise Ratio | >56dB |
IR LED Range | Up to 30m (98 ft) IR range |
WDR | 120dB |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
H.264 code profile | Baseline profile, Main Profile, High Profile |
Maximum Frame Rate / Stream | Main: 4MP (2688 x 1520) @ 30fps Sub: 720P (1280 x 720) @ 30fps |
HLC, BLC, 9:16 Corridor, Defog, Flip | Supported |
OSD, Privacy Mask, Motion Detection & ROI |
Up to 8 areas |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL |
Compatible Integration | ONVIF (Profile S, Profile T), API |
Network | RJ45, 10M/100M Base-T X Ethernet |
Smart Intrusion Prevention | Cross Line, Intrusion, Enter/Leave Area Detection |
Local Storage | Micro-SD, up to 256GB |
Network Storage | Automatic Network Replenishment (ANR) |
General | |
Power | 12 V DC, PoE (IEEE802.3 af); Power consumption: Max 6W |
Dimensions (Ø x H) & Weight | Φ118 x 95mm (Ø4.6 x 3.8”); 0.35kg (0.77lb) |
Audio I/O & Compression | Built-in Mic; G.711 Compression |
Operating Temperature & Humidity |
-30°C ~ +60°C (-22°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing) |
Conformity Certifications | IP67, CE, FCC |
