Key Features
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- High Video Quality with 5MP, 2880 x 1620 Resolution
- High Definition Analog (HD Analog) over Coax Technology, utilizes existing Coax Cables & BNC Connectors, allowing Mega-pixel Video Images without any rewiring necessary
- TVI, AHD, CVI and CVBS Protocol selectable --- Engineered to work with UVT Hybrid NVR’s for Maximum Stability and Performance
- Smart IR LED Lights for 0Lux Night Time Operation up to 65 Feet
- 2.8mm fixed lens
- TRUE Day/Night and DWDR functionality for all Lighting Conditions
- Backlight Compensation and 2D DNR (Digital Noise Reduction)
- Supports 180° horizontal flip, 180° vertical flip
- Easy to Operation On Screen Display (OSD) Configuration Menu
- 12VDC Power Options; IP67 Weather Resistant Housing with Optional Mounts
- Supported by uniview tec Guard Station Client Software and Guard Viewer Mobile App’s for iPhone and Android Devices
Sensor | |
---|---|
Pixel | 2MP |
Size | 1/2.7" CMOS |
Minimum illumination | 0.02 lux (F2.0, AGC ON) 0 lux (IR on) |
Lens | |
Focal Length | 2.8mm |
Angle of View (H x V) | 102.2° x 53.9° |
IR Illumination | |
IR LED Range | 20M (65ft |
Video | |
Resolution | 5MP @ 25fps: 2880 × 1620; 5MP @ 20fps: 2592 × 1944; 5MP @ 12.5fps: 2592 × 1944 4MP: 2560 × 1440 1080P: 1920 × 1080 |
Frame rate | TVI: 5MP @ 20fps, 5MP @ 12.5fps, 4MP @ 30fps, 4MP @ 25fps, 1080P @ 30fps, 1080P @ 25fps AHD: 5MP @ 20fps, 4MP @ 30fps, 4MP @ 25fps, 1080P @ 30fps, 1080P @ 25fps CVI: 5MP @ 25fps, 4MP @ 30fps, 4MP @ 25fps, 1080P @ 30fps, 1080P @ 25fps CVBS: PAL, NTSC |
Shutter time | PAL: 1/25s-1/50000s NTSC: 1/30s–1/50000s |
Image | |
Exposure mode | 4 modes: Global (default), BLC, HLC, DWDR |
Day/Night | 3 modes: Auto (default), Day, Night |
Digital noise reduction | 2D |
White balance | Two modes: Auto (default), Manual |
WDR | DWDR |
Smart IR | Support |
Flip | Supports 180° horizontal flip, 180° vertical flip. |
Interface | |
Power | 5.5mm power interface |
Video output | BNC, supports TVI / AHD / CVI / CVBS |
Operating Environment | |
Temperature | -30℃ to 60℃ (-22℉ to 140℉) |
Humidity | ≤95% (RH, non-condensing) |
Surge protection | 4KV |
Ingress protection | IP67 |
General | |
Power | DC 12V(±25%), with reverse polarity protection and surge protection, Max 3.6W |
Mount | Surface mount (default); optional junction box and wall mount available |
Dimensions (Dia x H) | Φ118 x 96mm (4.6 x 3.8”) |
Material | Plastic |
Weight | 182g (0.40lb) |
Certification | CE, FCC |
