Key Features
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- LightHunter Technology for ultra-high quality color video images in low light applications with up 5MP, 2880 x 1620 Resolution
- Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
- Powerful, Smart IR LED Lights for 0Lux Night Time Operation up to 131 Feet
- 2.8mm fixed lens, TRUE Day/Night and WDR functionality for all Lighting Conditions
- Built-in microphone, Corridor View, Backlight Compensation and 3D DNR (Digital Noise Reduction)
- Triple Video Streams, ONVIF Profile S Compliant
- Intelligent Perimeter Protection with Smart Intrusion Detection Analytics
- PoE & 12VDC Power Options
- Built-in Micro-SD Card Slot enables local storage up to 256GB
- IP67 Weather Resistant Housing
- Optional Mounts Available
- Supported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Devices
Camera | |
---|---|
Sensor | 1/2.7", progressive scan , 5 megapixel, CMOS |
Lens | 2.8mm@ F1.6 |
Angle of View (H x V) | 112.7° x 60.1° |
Shutter | Auto/Manual, 1 ~ 1/100000s |
Minimum Illumination | Color: 0.003 Lux (F1.6, AGC ON); 0 Lux with IR |
Day/Night | IR-cut filter with auto switch (ICR) |
Digital noise reduction | 2D/3D DNR |
IR LED Range | Up to 40m (131 ft) IR range |
WDR | 120dB |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
H.264 code profile | Baseline profile, Main Profile, High Profile |
Maximum Frame Rate / Stream | Main Stream: 5MP (2880 x 1620) @ 25 fps Sub: D1 (720 x 576) @ 30fps Third Stream: CIF (352 x 268) @ 30fps |
HLC, BLC, 9:16 Corridor, Defog, Flip, Dewarping |
Supported |
OSD, Privacy Mask, Motion Detection & ROI |
Up to 8 areas |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL |
Compatible Integration | ONVIF (Profiles S, G, T), API |
Network | RJ45, 10M/100M Base-TX Ethernet |
Local Storage | Micro-SD, up to 256GB |
Network Storage | Automatic Network Replenishment (ANR) |
Smart Intrusion Prevention | Cross Line, Intrusion, Enter/Leave Area Detection |
General | |
Power | 12VDC +/- 25%,; PoE (IEEE802.3 af); Max 6.4W |
Dimensions (Ø x H) & Weight | 155.9 × 63.1 × 62.7mm (6.1 × 2.5 × 2.5”); 0.425kg (0.93lb) |
Audio I / O & Compression | Built-in microphone; G.711 Compression |
Operating Temperature & Humidity | -30°C ~ +60°C (-22°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing) |
Conformity Certifications | IP67, CE, FCC |
