Key Features
- Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
- Exceptional Video Quality with 5MP, 2880 x 1620 Resolution
- Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
- Powerful, Smart IR LED Lights for 0Lux Night Time Operation up to 131 Feet
- 2.8 ~ 12mm motorized varifocal, automatic focus lens
- TRUE Day/Night and WDR functionality for all Lighting Conditions
- Built-in microphone, Corridor View, Backlight Compensation, 3D DNR (Digital Noise Reduction)
- Dual Video Streams, ONVIF Profile Series Compliant
- PoE & 12VDC Power Options and Optional Mounts Available
- Built-in Micro-SD Card Slot enables local storage up to 256GB
- IP67 Weather Resistant and IK10 Vandal Resistant Rated Vandal Housing
- Supported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Devices
Camera | |
---|---|
Sensor | 1/2.7", progressive scan , 5 megapixel, CMOS |
Lens | 2.8~12 mm, varifocal automatic focusing and motorized zoom lens |
Angle of View (H x V) | 108.79° ~ 33.23° x 56.9° ~ 18.33° (Wide ~ Tele) |
Shutter | Auto/Manual, 1 ~ 1/100000 s |
Minimum Illumination | Color: 0.003 Lux (F1.6, AGC ON); 0 Lux with IR |
Day/Night | IR-cut filter with auto switch (ICR) |
Digital noise reduction | 2D/3D DNR |
Signal /Noise Ratio | 52dB |
IR LED Range | Up to 40m (131 ft) IR range |
WDR | 120dB |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
H.264 code profile | Baseline profile, Main Profile, High Profile |
Maximum Frame Rate / Stream | Main: 5MP (2880 x 1620) @ 25fps Sub: 720P (1280 x 720) @ 30fps |
HLC, BLC, Digital Defog, Flip | Supported |
OSD, Privacy Mask, Motion Detection & ROI |
Up to 8 areas |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL |
Local Edge Storage | Micro-SD, up to 256GB |
Network Storage | Automatic Network Replenishment (ANR) |
Smart Intrusion Prevention | Cross Line, Intrusion, Enter/Leave Area Detection |
Compatible Integration | ONVIF (Profile S, Profile T), API |
Network | RJ45, 10M/100M Base-TX Ethernet |
General | |
Power | 12VDC +/- 25%, PoE (IEEE802.3 af); Power consumption: Max 7.5W |
Dimensions (Ø x H) & Weight | Φ128 x 100mm (Ø5.0 x 3.9”); 0.65kg (1.43lb) |
Audio & Compression | Built-in Mic; G.711 Compression |
Operating Temperature & Humidity |
-30°C ~ +60°C (-22°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing) |
Conformity Certifications | IP67, IK10; CE, FCC |
